After completing the Define phase in the DMAIC approach, the Measure phase is the next step. This phase aims to collect data to understand the current process and establish a baseline for improvement. Deliverables in this phase provide critical insights into the process performance and help identify opportunities for improvement. This article will discuss the essential deliverables expected during the Measure phase.

1. Data Collection Plan:

A Data Collection Plan outlines the data to be collected, the methods used, and the resources required for data collection. It helps to ensure that the data collected is reliable and consistent. A well-designed Data Collection Plan can save time and reduce errors in data collection. The data collection plan should also outline any tools or resources needed to collect the data and any potential risks associated with managing it. This deliverable is crucial for the Measure phase, forming the basis for all subsequent data collection activities.

2. Baseline Process Performance Metrics:

Process Performance Metrics are used to measure how well a process is performing. These metrics provide quantitative data that can be used to identify areas for improvement. Common metrics used in the Measure phase include cycle time, defect rate, and process capacity. Collecting data on these metrics helps the team to identify which areas of the process are performing poorly and focus their efforts on improving them.

3. Measurement System Analysis (MSA):

Measurement System Analysis (MSA) evaluates the reliability and accuracy of the measurement system. Ensuring that the data collected during the Measure phase is accurate and reliable is crucial. MSA can be used to identify any sources of variability in the measurement system and improve the accuracy and reliability of the data. This deliverable helps to ensure that the data collected is of high quality and can be used to make informed decisions.

4. Value Stream Map (VSM) - Current State Map:

A Value Stream Map (VSM) visually represents the current process. It provides a high-level overview of the process and helps identify improvement areas. A VSM includes information on each process step's materials, resources, and activities. At the end of the measure phase, the project team should clearly understand how the process works (current state map).

5. Control Charts (current level of performance)

Control Charts are used to monitor a process over time. They provide information on the stability of the process and help identify any special causes of variation (e.g., sudden changes in performance). Control Charts also help identify potential improvement areas by highlighting data points that are not in line with expected performance. The team should develop Control Charts for each metric monitored during the Measure phase. This will provide a performance baseline and help identify improvement areas.


The Measure phase of the DMAIC approach is a critical step in process improvement. This phase involves collecting data and establishing a baseline for performance. The key deliverables in this phase are the Data Collection Plan, Baseline Process Performance Metrics, Measurement System Analysis (MSA), Value Stream Map (VSM) - Current State Map, and Control Charts (current level of performance). These deliverables provide insights into the process's performance and help identify improvement areas.
